Pharmapack (GUANGZHOU) Packaging Equipment Co., Ltd

According to the size of the desiccant, the corresponding parameters are set on the touch screen to control the clamping feeding device. When clamping feeding belt drives the sachets to feed, the uncoiling device uncoils the desiccant roll for feeding. The fixed length conveying part sends the desiccant to the I- mark detection station, where the I-mark sensor detects the sachet and send the signal to PLC. Maximal speed is 18,000 per hour.

The machine is widely used for cotton inserting into a bottle, in which tablets, pills, capsules or other dry medicament are filled, which is mainly used in pharmaceutical, health care, foodstuff and other industries. Servo-motor control system makes sure accurate controlling. The machine also has compact configuration, elegant structure and convenient operation. Output is up to 120 bottles per minute.

The machine is widely used for cotton inserting into a bottle, in which tablets, pills, capsules or other dry medicament are filled, which is mainly used in pharmaceutical, health care, foodstuff and other industries. Servo-motor control system makes sure accurate controlling. The machine also has compact configuration, elegant structure and convenient operation. Output is up to 200 bottles per minute.

The machine is composed of 4 single modules, continuous screw servo infeeding system, servo system, rejecting star wheel servo system and others. It is made of high-quality stainless steel, compact appearance, simple structure, convenient maintenance. It can be widely used in the pharmaceutical industry for production of solid drugs, such as pills, tablets, soft and hard capsules and other shaped tablets.

The machine is composed of 4 single modules, continuous screw servo infeeding system, servo system, rejecting star wheel servo system and others. It is made of high-quality stainless steel, compact appearance, simple structure, convenient maintenance. It can be widely used in the pharmaceutical industry for production of solid drugs, such as pills, tablets, soft and hard capsules and other shaped tablets.

This is a tablet counting and filling machine. It’s designed specifically for the pharmaceutical, healthcare, and food industries. Filling range is 1 – 1,000 tablets/ capsules. Output is 12,000 pcs/ min. Applicable tablets and capsules must be within 3 – 20 mm in diameter. Multiple modular design concepts, which can better meet different customer requirements.

The machine uses non-contact non-destructive detection method. Leaks are detected by vacuum decay method, the production and testing process fully comply with the relevant requirements of GMP and ASTM F2338-09. Fast detection speed, continuous testing method, maximum stable speed up to 250 bottles/min.

The machine is mainly applicable for pharmaceutical, healthcare and food industries. The application materials are all kinds of impact-resistant container round bottles for slowing down and storing. The machine has the advantages of simple structure, easy operation, easy installation and transportation, low repair rate, convenient handling, and slowdown and storage function. The machine can be set to different speeds according to different requirements to meet various users' requirements.

Equipped with highly integrated single industrial computer control system with higher operability. The machine has ergonomics design, improved HMI, strong maintain-ability, complete visual cover design. Suspension rocker arm control panel mechanism, more convenient debugging operation. Maximal speed is 6,000 tablets per mi-nute.

The machine functions as an automatic counter counting and filling machine for pills, tablets, soft and hard capsules and other solid granules. It is widely used in pharmaceutical, health care, food, pesticide, chemical and other industries. Applicable volume per product is 1 – 1,000 pcs. Applicable bottle must be within 20 – 100 mm in diameter and 40 – 240 mm in height.
